29.1 Recommended torque settings: Campagnolo /Shimano /Avid /SRAM components
Component Bolted connection Campagnolo* Shimano** SRAM***
Nm Nm Nm
Rear gear changer Fastening bolt 15 8 - 10 8 - 10
(rear derailleur) Cable fixing bolt 6 4 - 6 4 - 5
Chain roller bolt 3 3 - 4
Front derailleur Fastening bolt 3.5 5 - 7 5 - 6.5
Cable fixing bolt 5 5 - 7 4.5
Brake/shift lever Mounting bracket bolt (Allen bolt) 10 6 - 8 5 - 7
Mounting bracket bolt (screwdriver) 2.5 - 3
Bolt of cable stop on frame (screwdriver) 1.5 - 2
Shifter fastening bolt (rapidfire) 2.5
Disc brakes Caliper bolt (fixation to frame) 7 5 - 7 (RW)/ 9 - 10 (FW)
Disc (rotor) fixing bolts 4
Hub Quick-release lever 9 - 12
Locknut for adjustment of quick-release hub bearing 3.5 10 - 25
Free-wheel hub Freewheel body fastening bolt 35 - 49 40
Freewheel body fastening nut 35 - 44
Sprocket cluster lock ring 29 - 49
Crank set Crank fixing bolt (cotterless, grease-free) 32 - 38 34 - 44
Crank fixing bolt (octalink) SRAM GXP 35 - 50 48 - 54
Chainwheel bolt 8 - 11
Sealed cartridge Shell 70 49 - 69 34 - 41
Bottom bracket
Pedal Pedal axle 40 34 31 - 34
Shoe Cleat bolts 5 - 8
Spike 4
(
Brake Fastening bolt (V-brake) 5 - 9 5 - 7
Fastening bolt (racing brake) 10 8 - 10
Cable fixing bolt 5 6 - 8 6 - 8
Brake pad fixing bolt 8 5 - 7 6 - 8
Pad fixing bolt in cartridge brake shoe 1 - 2
(
29. Recommended torques for bolted connections
* From Campagnolo technical specifications ** From Shimano Product Information and Tech Tips, *** From SRAM technical information / Avid installation and operating instructions/Truvativ instructions.
