29.2 Recommended torque settings: FSA components
Model no. Model name Bolts Nm
Stems ST-CX-120 XC-120 M5 Ti 8
ST-FR-200 FR-200 M5 Cromo 9
ST-FR-200 1,5 FR-200 One Point Five M6 Cromo 12
ST-RD-120 RD-120 M5 Cromo 9
ST-RK-100 K-Force Lite with Alloy Front Cap M5 Ti 8
ST-RK-100K K-Force Lite with Carbon Front Cap M5 Ti
ST-RK-200 K-Force M5 Ti 8
ST-DH-300 DH-300 M6 Cromo 12
ST-BX-400 Powder Keg M8 Cromo 18
ST-BX-400 1,5 Powder Keg One point Five M8 Cromo 18
All bottom brackets Alloy Cups 39.2 - 49
Crank bolts (ISIS) M8 steel 34 - 40
M12 steel 49 - 59
M14 steel 49 - 59
M14 aluminium 44 - 49
M15 steel 49 - 59
M15 aluminium 49 - 59
Crank bolts BB-527 (X-Drive DH) BB-527 (X-Drive DH) 3/8“ Cromo 39 - 49
BB-500 (Afterburner BMX) BB-500 (Afterburner BMX) M6-Thru Boron 39 - 49
BB-511 (X-Drive BMX/Flatland) BB-511 (X-Drive BMX/Flatland) 3/8“ Cromo 39 - 49
B-522 B-522 (Smack Daddy/Wild Child) M14 steel 39 - 49
BB-510 (CK40/Pig) BB-510 (CK40/Pig) M8 steel 39 - 49
Chainring bolts Allen Cromo 12
Allen aluminium 10
Torx aluminium 11
From FSA service instructions: Product Torque Specifications
29. Recommended torques for bolted connections
