Page 2/30
Contents:
Page
1. Main sub-assemblies within product 3
2. Signal routing through product 4
3. Basic functionality explained 5
4. Identification of main sub-assemblies 6
5. Location of main sub-assemblies 15
6. Disassembling the product 16
(6.1) Removing the Outer Cover Assembly 16
(6.2) Removing the Fascia assembly 16
(6.3) Removing the Display board 17
(6.4) Removing the Switch board 17
(6.5) Removing the Inner Lid 17
(6.6) Removing boards from the back-panel 18
7. Removing and replacing the PSU and Cap board 19
(7.1) An overview of the PSU and Cap board 19
(7.2) Removing and replacing a floor-mounted Cap board 20
(7.3) Removing and replacing a side-mounted Cap board 22
(7.4) Removing and replacing the older type of PSU 23
(7.5) Removing and replacing the newer type of PSU 27
8. Adjusting the output voltage of the PSU 28
9. Terminator cards – How many to fit and where to fit them 28
10. Reassembling the unit 30
(10.1) Fitting the Motherboard 30
