PM0480-16 MEGATOUCH ION EVO WALLETTE OWNER’S MANUAL 2
FIGURE 1 - EVO WALLETTE WITH CPU SECTION OPEN
FIGURE 2 - REAR VIEW OF EVO WALLETTE - CPU SECTION SLID TO THE LEFT
eVo Wallette Diagrams
MOTHERBOARD
POWER
SUPPLY
CPU SECTION
LOCK
HARD DRIVE
TOUCHSCREEN
CONTROLLER
WIRELESS
ADAPTER
MONITOR
CONTROLS
DETAIL VIEW OF
CONTROL BOARD
SECURITY
KEY
SETUP
CALIBRATE
USB PORT
PRINTER PORT
PHONE COUPLER
ETHERNET COUPLER
CASH DOOR LOCK
BACK PLATE
CENTRONICS
UPGRADE CONNECTOR
COVER PLATE
SECURED BY STANDOFF
INSIDE CPU SECTION
