Megatouch Ion eVo Wallette™ Replacement Parts List
NOTE: The parts in your game may vary. When calling for replacement
parts, make sure to have your serial number available to ensure the accuracy
of your order.
NOTE: In order for your Megatouch Ion game to function properly, the hard-
ware must only be replaced with Ion hardware. Replacing the motherboard,
I/O board, hard drive or touchscreen controller with hardware that is not spe-
cific for Ion will eliminate some of the Ion software features.
For additional assistance, after contacting your distributor, contact:
Merit Product Support and Services
USA and Canada call toll-free:
1-800-445-9353
Outside the USA and Canada call:
(215) 639-4700
FAX: (215) 639-5346
Merit Entertainment, P.O. Box 5004, Bensalem, PA 19020-8529.
You can also visit our Web site
www.meritgames.com
REPLACEMENT COMPONENTS
17” ION EVO WALLETTE (G52-200-00X-XX)
15” ION EVO WALLETTE (G52-000-12X-XX)
PART NUMBER DESCRIPTION
SA10070-01 ION MOTHERBOARD
EC9796-04 MARS BILL ACCEPTOR, $1/2/5, 300 STKR, AE2411
HW8159-01 MECHANICAL COIN MECH
EC7538-02 POWER SUPPLY, 200W ±12,+5,+3.3
EC9851-09
EC9850-11
17” TOUCHSCREEN OVERLAY or
15” TOUCHSCREEN OVERLAY
EC9384-05
EC9388-06
17" LCD or
15" LCD
EC9846-01 TOUCHSCREEN CONTROLLER
SA10068-03 I/O BOARD
SA10066-01 CONTROL BOARD
SA3522-XX ION 2007 KEY
PA3028-01 ION 2007 HARD DRIVE
39 MEGATOUCH ION EVO WALLETTE OWNER’S MANUAL PM0480-16
