COPYRIGHT © 2008 MERIT ENTERTAINMENT
FIGURE 30 - THE ION EVO WITH CPU SECTION OPEN
CPU SECTION
LOCK
TOUCHSCREEN
CONTROLLER
WIRELESS
ADAPTER
MONITOR
CONTROLS
DETAIL VIEW OF
CONTROL BOARD
SECURITY
KEY
SETUP
CALIBRATE
POWER
SUPPLY
HARD DRIVE
MOTHERBOARD
STANDOFF SECURING
COVER PLATE ON
BACK OF CPU SECTION
PM0426-25 MEGATOUCH ION EVO OWNER’S MANUAL 36
