COPYRIGHT © 2000 MERIT INDUSTRIES, INC.
PM0075-03 Rev C Scorpion™ DX Manual 1
Introduction
The Scorpion™ DX dart machine features
an LCD panel
a card reader
a keypad
x86 based CPU
1 meg RAM
(expandable to 2 meg)
Flash Memory Drive
two PCM/CIA slots
NV RAM w/Clock
Variable overhead
PC104 BUS
The same size cabinet as all
Scorpion models
The Scorpion™ DX makes use of an “ATM-style” interface, where the individual
button functions are determined by the information displayed on the screen. Press-
ing a button that corresponds to a desired game/option icon will activate that game/
option. References, in this manual, to “pressing a button” mean to press the button
corresponding to the icon displayed on the screen.
