Merrychef eikon e5 Quick Start Guide

8
Quick Service Guide original instructions
Part Number 32Z3802 US Issue 3
PRODUCT DETAILS
MAIN FEATURES
ON/OFF SWITCH1
When switched ON the easyToUCH screen illuminates the oven
controls. Note; turning this switch OFF does not isolate the oven from
the electricity supply.
easyToUCH SCREEN CONTROL PANEL2
See ‘OPERATION & CONTROLS’ for details.
RATING PLATE3
Located on the rear panel of the oven states the serial number, model
type & electrical specications.
MenuConnect™ 4
A USB socket located under the Merrychef logo allows changes to
programs stored on the oven (See USB MenuConnect™ User Manual,
and Operation & Controls section of this manual, for details of
updating oven programs).
AIR OUTLETS5
Air used to cool internal components and steam from the cavity
escape through the air outlet vents located on the rear of the oven
and side panel of the e5 model. The air outlets must be kept free from
obstruction and they will not allow microwave energy to escape into
the environment.
AIR INLET FILTER6
The air lter situated at the lower front of the oven is part of the
ventilation system and must be kept free of obstruction and cleaned
daily as described under ‘Cleaning & Maintenance’. Note, the oven will
not operate without the air lter tted.
DOOR HANDLE7
This is a rigid bar which is pulled downwards and away from the oven
to open.
OVEN DOOR8
This is a precision-made energy barrier with three microwave safety
interlocks. The door must be kept clean (see ‘CLEANING’) and should
NOT be used to support heavy objects.
DOOR SEALS9
These ensure a tight seal around the door. They should be kept clean
and checked regularly for signs of damage. At the rst sign of wear
they should be replaced by a Merrychef approved Service Agent.
CONVECTION FAN, GREASE FILTER & CATALYTIC CONVERTOR 10
(model dependant)
The metal grease lter grill covering the convection fan must be kept
clean and free of debris. Great care should be taken when cleaning
this area of the oven noting the dierent oven requirements shown
under ‘Cleaning & Maintenance’ in this manual.
OVEN CAVITY11
The oven cavity is constructed from stainless steel and must be
kept clean by following the cleaning instructions in the ‘Cleaning &
Maintenance’ section of this manual.
