supplies), connect the external power source here. The
internalbatteryisautomaticallydisconnectedbyaswitch-
ingelementintheExternalDCReceptacleonthepedal.
However,ifyouknowyouwillnotbeusing batterypower
foranextendedperiod–forexample,ifyouaremounting
theunittoyourpedalboardpermanently-itiswisetore-
movethebatterytoavoidpossibledamagefromlong-term
batterycorrosion.
INTERNAL BATTERY:
Thisunitcanoperateoneithera
9-Voltbatteryorastandard9-Volt“wall-wart”powersupply.
TheunitisshippedfromtheFactorywithalong-life9-Volt
Battery tofacilitateeasier trialdemonstration in amusic
storeenvironment.
NOTE: The internal battery is switched to an “ON” state
(drawing voltage) by a switching element in the INPUT jack.
Disconnect the cable from the ¼” INPUT jack whenever the
unit is not in use to prolong battery life.
BATTERY REPLACEMENT:
Toaccessthe9-Voltbat-
teryforinspection,replacementorremoval;makesurethe
ExternalPowerjackisdisconnected,removethefourPhil-
lips-headscrewsfromthefourcornersofthebottomlid
andremoveit,notetheorientation/directionofthebattery
andterminals–andremoveit.Replaceifnecessary.
NOTE: Any type of 9-Volt battery will work in this device if
it is fully charged and functional. Carbon Zinc, Alkaline or
even Nickel Cadmium Rechargeable type batteries are all
acceptable replacements. Some pedal aficionados prefer
the “sweetness” they claim to hear from standard Carbon
Zinc type batteries, but you will have to decide what type
best serves your needs.
SPECIFICATIONS:
• Dimensions (W/D/H): 2.87” x 4.77” x 2.28” (73mm x
122mmx58mm)
• Weight: 0.802lbs(364g)with battery, 0.702lbs (319g)
withoutbattery
• TrueBypassSwitching
• BatteryType:9VDC(one)
• PowerConsumption(CurrentDraw):9VDC/15mA
• ACAdapter (Optional): Power Jack 2.1mm x5.5mm,
9VDCwithNegativeCenter (Regulated Recommend-
ed)
• InputImpedance:1MOhm(500kOhmminimum)
• OutputImpedance:10kOhm
SAMPLE SETTINGS: SAMPLE SETTINGS: USER SETTINGS:
MID-GAIN CRUNCH FLUX BUMP
SINGING SOLO SLAM IT

Mesa/Boogie Flux-drive Specifications
