PAGE 1
Congratulations on your choice of the M3 Carbine and welcome to the Mesa/Boogie Family!
First we would like to thank you for choosing us as your amplifier company and trusting us to help create your musical voice. This
is something we never take for granted and you’ll find that we are here ready to assist you should you ever need help. Our goal is
to help you sound your best at all times! We feel confident that your new amplifier will bring you many years of reliable service and
rewarding inspiration and create for you a newfound freedom to express through your music.
The M3 Carbine expands the MESA Family of Bass amplifiers with an exciting new voice that’s super fast and extremely focused!
The output section relies on the same time-proven array of custom designed mosfets used in our M-Pulse, Big Block 750 and Titan
models, but the preamp and driver section are all new creating a very different feel and attitude.
Up front the tube preamp utilizes a standard tone control string of Bass, Mid and Treble to shape the basic sound, but the shaping
power doesn’t stop there. There is a PULL DEEP feature found on the Bass control that keeps the low end tight and articulate when
pushed in or, enhances the sub-lows and adds super-top air when pulled out.
DI LEVEL and MASTER controls make adjusting your playing volume levels quick and easy on stage. The DI LEVEL features both
post and pre Tone control options, with post being the default (pushed in) setting and PULL PRE activating the pre setting that by-
passes the entire preamp. A TUNER MUTE pull pot is added to the MASTER Output control for silent tuning in live or studio applica-
tions. This feature can also be triggered remotely from the Rear Panel Function Switch jack labeled MUTE.
Ov e r v i e w :
Operating Instructions
VACUUM T UBE PREAMPLIFIER
MOSFET POWER
HAND BUILT IN PETALUMA, CALIFORNIA
120 V~
60 Hz
5 A
6.25 A
WARNING:
Replace fuse with same type/rating only.
Do not expose to rain or moisture.
CAUTION:
Risk of Electric Shock. Do Not Open.
No user serviceable parts inside.
®
F
U
S
E
F
U
S
E
MID
INPUT
CLIP
®
INPUT
TRANS-CLASS
™
FRONT VIEW: M3 CARBINE
REAR VIEW: M3 CARBINE
