Mesa/Boogie TransAtlantic TA-15 User Manual

PAGE 31
CAUTION: Unplug power before replacing fuse
120 V~
60 Hz
1 A
1.25 A
SLO BLO
SPEAKERS
8 OHM
PATENTED
6,621,907 7,173,488 7,602,927
CAUTION: CHASSIS SURFACE MAY BE HOT!
4 OHM
TRANSATLANTIC
TA-15
HANDBUILT IN PETALUMA, CAALL TUBE AMPLIFIER
®
CAUT ION !
WAR NIN G!
TUBE GUIDE
4 x 12AX7
2 x EL 84
F
U
S
E
F
U
S
E
INPUT
FT SW
VOLUME TREBLE BASS GAIN TREBLE BASS MASTER
POWER
STANDBY
NORMAL
15 15
HI 1
TOP BST
25W
FT
SW
5W
TWEED
HI 2
25W
5W
ON ON
MASTER
PULL
CUT /
™
-15
ALL FRONT PANEL KNOBS
PT# 408620
FRONT PANEL: Tr a n s aT l a n T i c TA-15 REAR PANEL: Tr a n s aT l a n T i c TA-15
JACK x 2
pt# 619112
A.C. RECEPTACLE
pt# 613714
SWITCH x 2
pt# 600626
SWITCH
pt# 607231
SWITCH pt# 607233
RED LED pt# 394201
RED LED
pt# 394201
590155 590792 590739 590750 590792 590738 590792 590792
DOM-FUSE pt#
795125
EXP-FUSE pt#
795630
HOLDER pt#
790347
HOLDER pt#
790346
JACK x 2
pt# 619112
SWITCH x 3
pt# 607233

Mesa/Boogie TransAtlantic TA-15 Specifications

General

Brand	Mesa/Boogie
Model	TransAtlantic TA-15
Category	Musical Instrument Amplifier
Language	English
