9. Technical Specifications
Basic 250-24 W Basic 250-50 W
Suction capacity l/min 200 200
Free air delivery (volume flow rate) l/min 95 95
Filling rate l/min 110 110
Max. working pressure bar 8 8
Max. storage / operating temperature *) °C + 40 + 40
Min. storage / operating temperature **) °C + 5 + 5
Pressure vessel volume l 24 50
No. of air outlets 1 1
No. of cylinders 1 1
Motor speed min
-1
2850 2850
Motor capacity kW 1.5 1.5
Supply voltage (50 Hz) V 230 230
Rated current A 6.0 6.0
Fuse protection min. A 10 (time-lag) 10 (time-lag)
Degree of protection IP 20 IP 20
Maximum total calbe length when using extension cables:
– at 3 x 1.0 mm
2
lead cross-section
– at 3 x 1.5 mm
2
lead cross-section
– at 3 x 2.5 mm
2
lead cross-section
m
m
m
10
25
25
10
25
25
Required oil quantity (pump) / Oil grade (pump) l approx. 0.25 / SAE 20 approx. 0.25 / SAE 20
Dimensions: length x width x height mm 630 x 406 x 630 830 x 445 x 715
Weight kg 27 31
Sound pressure level L
PA
at 1 m maximum dB (A) 97 ± 3 97 ± 3
Sound power level L
WA
dB (A) 97 ± 3 97 ± 3
All specifications refer to 20 °C ambient temperature.
*) The service life of certain components, e.g. the gasket in the check valve, is greatly reduced when operating the compressor at
high temperatures (maximum storage/operating temperature and above).
**) At temperatures below the minimum storage/operating temperature there is a risk of the condensate freezing in the pressure
vessel.
