Interfaces
• 2 x RS232 DB-9 DCE
• 2 x RJ-45 connectors
• 1 x SMA Antenna connector
• 1 x AC Power Connector
LED Indicators
• Power Blue
o Permanently ON if power is applied
• Network Green
o Slow flash every one second: Not registered on GSM network
o Short 75ms flash every 3 seconds: Registered on GSM network
o Double flash every 3 seconds: Registered on GPRS/EDGE
• Status Orange/Red
o On if WAN interface is up
• Transmit Green
o Application specific
• Receive Green
o Application specific
• LAN 1 Orange
o On if connected
• LAN 2 Orange
o On if connected
• SIM 1 Green
o On if SIM 1 is being used
• SIM 2 Green
o On if SIM 2 is being used
Hardware Watchdog
The hardware watchdog can only be used by specialized software on the router.
