1. Index
The header on each page defines the user group particular information is
aimed at.
Chapter Page
1. Index 2
2. Explanation of the pictograms 2
3. General information 3
4. Application 4
5. Construction 4
6. Explanation of the type plate 4
7. Technical data 5
8. Functional description 5
9. Installation options 6
10. Guidelines for installation 7
11. Hose connections 8
12. Electrical connections 8
13. Description of the external display 9
14. Replacement of the collection container 10
15. Disposal of the full container 11
16. Maintenance, cleaning and disinfection 12
17. Service mode 13
18. Annual inspection 14
19. 5-year inspection 15
2. Explanation of the pictograms
i
Information
Caution!
General warning sign
Refer to instruction manual/booklet
Index  Explanation of the pictograms
Practice personnel, technicians
