Meteor Lion ZigBee - Chapter 3 BarCode parameters setting; 3.1 UPC-A

- 12 -
Chapter 3 - BarCode parameters setting
How to set up a Code ID?
(1) Scan Start configuration bar code
(2) Go to the ASCII Table and scan label that represent the desired
characters to be inserted.
(3) Scan Confirm configuration bar code
(4) Scan End configuration bar code.
Start configuration End configuration
Confirm configuration
3.1 UPC-A
ITEM OPTION
Disable
Read
* Enable
Code ID Setting
(Default : F )
Ref: Appendix (20-7EH)
