3. SYSTEM
This section describes the specifications and components of the AROYA Gateway, Repeater,
Climate Station, and Sensor Nose.
3.1 SPECIFICATIONS
MEASUREMENT SPECIFICATION
ATMOS 14 Temperature and Relative Humidity (RH) Sensor
Relative Humidity (RH)
Range 0–100% RH (0.00–1.00)
Resolution 0.10% RH
Accuracy Sensor measurement accuracy is variable across a range
of RH. Refer to the chart in Figure 3.
Figure 3 RH sensor accuracy
Equilibration Time
(t,63%)
<25 s (response time in 1 m/s air stream)
Hysteresis
±0.80% RH, typical
Long-Term Drift
±0.25% RH/year, typical
Temperature
Range
–40 to 80 °C
Resolution
0.1 °C
