2.11.2010 Rev. 3.0
Installation
8
5.4 Electricity connections
Should maintenance require the appliance to be tested before all the protective coverings
are in place, please be particularly careful of the moving parts inside the casing as well as
of live parts.
To facilitate future maintenance and to increase safety, install a separate disconnection
switch for the range in the immediate vicinity of the appliance. The switch should discon-
nect the appliance completely from the mains supply.
The supply cable inlet is in the back right-hand corner of the range and the connection
point inside the range.
The top deck needs to be open to connect the range to the mains. Unfix the screws at the
front part of the flat top and raise the deck up.
Be cautious when opening the deck because of its weight and always lock the deck into
the open position with the fixing rod.
In case of combination of a range and an oven, the connection point for the supply cable
is located on the rear wall of the oven (right low corner). In order to make the connection,
the right side panel of the oven must be removed.
All information needed to connect the range is to be found on the name plate, the connec-
tion diagram and the installation drawing.
5.5 Test-run
Please read the safety and operation instructions as well as the functional description of
the appliance before testing the range.
Test the range once it has been connected to the mains electricity.
Check that every cooking zone heats up and the corresponding pilot light turns on when
the zone is switched on with the power regulator.
Close and fasten the top deck.
