2
1. Engage the parking brake, then place
the gear selector in the lowest position.
2. Unclip, unplug, and remove the
dashboard trim panel. (Figure A)
3. Depress the tabs securing the radio
and slide the radio out in one motion.
Unplug and remove the radio.
Continue to Kit Preparation
DASH DISASSEMBLY KIT PREPARATION
(Figure A)
1. Place the cut template over the
dashboard trim panel. (Figure A)
2. Using a scribe tool, score the area in the
radio section to be cut. (Figure B)
3. Remove the cut template, then cut the
scored area with a cutting tool.
4. Clip the radio trim panel onto the
dashboard trim panel. (Figure C)
Continue to Kit Assembly
Remove shaded area
(Figure A)
(Figure B)
(Figure C)
