Metra Electronics 95-3105 - Dash Disassembly

95-3105
DASH DISASSEMBLY
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Remove (2) pop-clips from the sides
of the radio trim bezel. (Figure A)
2
SATURN (ALL MODELS) 1995-99
Unclip the radio trim bezel, discon-
nect the switch wiring and remove
the bezel. (Figure A)
3
Remove (2) 7mm hex-head screws
securing the top of the factory head
unit and disconnect the wiring.
(Figure B)
4
A
B
