95-3314G
Kit Assembly
(Figure A) (Figure B)
ISO DDIN radio provision
1. Install the panel clips onto the
radio housing panel. (Figure A)
2. Attach the upper pocket with the
provided (4) #8 x 3/8” Phillips
screws. (Figure A)
3. Attach the radio brackets to the
aftermarket radio with the screws
supplied with the radio. (Figure B)
4. Locate the factory wiring harness
and antenna plug in the dash.
Metra recommends using the
proper mating adapters from Metra
and/or AXXESS.
5. Mount the new radio assembly into
the dash and reassemble dash in
reverse order of disassembly using
the 95-3314G radio housing panel.
