95-5025 KIT ASSEMBLY
A
Locate the factory wiring harness in
the dash. Metra recommends using
the proper mating adapter from Metra
or AXXESS. Re-connect the negative
battery terminal and test the unit for
proper operation.
1
Attach the Double DIN brackets to the
Double DIN radio or stacked ISO head
units using the screws supplied with
the radio.
(Figure A)
2
3
B
Mount the head unit/ kit assembly to
the dash using the four supplied # 8 x
1” Phillips screws.
(Figure B)
DOUBLE DIN HEAD UNIT PROVISION/
ISO STACKED HEAD UNIT PROVISION
1-800-221-0932
REV. 08-19-09 © COPYRIGHT 2009 METRA ELECTRONICS CORPORATION INST95-5025
www.metraonline.com
