95-5818 KIT/FINAL ASSEMBLY
2
DOUBLE DIN/STACKED ISO MOUNT
UNIT(S) PROVISION
Attach the double DIN brackets to
the double DIN or stacked ISO Mount
unit(s) using the screws supplied
with the unit(s).
(Figure A)
1
*Note: Refer also to the instructions included with the aftermarket radio.
A
NOTE: Major sub dash modifications are necessary to use this dash kit. You will
need to trim the sub dash to gain suitable depth and height.
B
A
B
C
D
(A) Strip wire ends back 1/2"
B) Twist ends together
C) Solder
D) Tape
Locate the factory wiring harness in
the dash. Metra recommends using
the proper mating adapter and mak-
ing the connections as shown.
(Isolate and individually tape off the
ends of any unused wires to prevent
electrical short circuit).
(Figure B)
Re-connect the negative battery ter-
minal and test the unit for proper
operation.
