1. Unclip and remove entire panel
including the radio and climate controls.
(Figure A)
2. Remove (4) Phillips screws to remove
radio from sub-dash. (Figure B)
3. Unsnap and remove the outer trim rings
around A/C control knobs. (Figure C)
Continued on next page
3
Nissan Titan 2004-2007
Nissan Pathfinder Armada 2004-2005
Dash Disassembly 95-7406
(Figure A)
OFF
(Figure C)
(Figure B)
To Next Page
