Metra Electronics 95-7406 - Page 4

4
Dash Disassembly 95-7406
Nissan Titan 2004-2007
Nissan Pathfinder Armada 2004-2005
4. Remove (4) T-10 Torx screws from the
A/C controls to remove from the factory
radio trim panel. (Figure D)
5. Unclip and remove the hazard light
switch assembly.
6. Remove (2) T10 Torx screws from the
passenger air bag off light assembly
and remove. (Figure D)
Note: The small round sticker also
needs to be removed from the factory
panel and placed onto the 95-7406
radio housing trim panel.
Continue to kit preparation
CLIP
HAZARD SWITCH
PASSENGER AIR BAG LIGHT
T-10 TORX
SCREW
T-10 TORX
SCREW
A/C CONTROL PANEL
INSIDE VIEW - RADIO TRIM PANEL BACK
1
2
3
4
T-10 TORX SCREWS
T-10 TORX SCREWS
1
2
(Figure D)
