H
2
6
Remove (3) Phillips screws securing
the factory display harness to the
radio chassis. Unplug and remove
display harness. (Retain display har-
ness for re-use during kit assembly.)
(
Figure H)
Remove (2) Phillips screws from the
bottom of the radio/climate control
panel. (
Figure F)
8
Unsnap radio/climate control panel
including radio chassis. Unplug and
remove panel and chassis. (
Figure G)
7
Remove (4) screws securing the radio
chassis to the radio/climate control
panel. (
Figure I)
9
Remove (6) screws securing the cli-
mate controls from the radio/climate
control panel. Unplug and remove the
climate controls. (Retain the screws
and climate controls for re-use during
kit assembly.) (
Figure J)
10
Continued on page 3.
