Metra Electronics 95-7802CH - Kit Preparation; Attach Factory Panel Clips; Attach Factory Hazard Button; Kit Assembly

95-7802CH
®
Kit AssemblyKit Preparation
To the radio housing:
1. Attach the (6) factory panel clips.
(Figure A)
2. Attach the factory hazard button
using the factory screws. (Figure B)
Continue to Kit Assembly
3
(Figure A)
ISO DDIN radio provision
1. Attach the radio brackets to the
radio using the screws supplied
with the radio. (Figure A)
2. Locate the factory wiring harness
and antenna plug in the dash.
Metra recommends using the
proper mating adapters from
Metra and/or AXXESS.
3. Secure the radio into the dash and
reassemble the dash in reverse
order of disassembly.
(Figure A)
(Figure B)
