Metra Electronics 95-7812B - Dash Disassembly; Remove Side Trim Panels; Remove Climate Control Panel; Remove Radio Mounting Screws

95-7812B
2
1. Unsnap and remove the side trim
panels from the center console.
(Figure A)
2. Unsnap and remove the climate
control panel. (Figure B)
3. Remove (2) Philips screws securing
the radio and then remove.
(Figure C)
Continue to kit assembly
Dash Disassembly
(Figure B)(Figure A) (Figure C)
