Metra Electronics 95-7815B - Page 4

1.800.221.0932
|
MetraOnline.com
4
DASH DISASSEMBLY
(CONT.)
7. Unclip and remove the shift lever trim
panels, then remove (2) Phillips screws
to remove the lower console storage
pocket. (Figure F)
8. Unclip, unplug, and remove the vent
assembly from above the radio.
(Figure G)
Continued on the next page
(Figure F) (Figure G)
