REV. 7/11/2017 INST95-7815B
4. Drop the glove box door, remove (2)
Phillips screws, and (2) push pins to drop
the glove box assembly. (Figure C)
5. Remove (1) push pin and remove the
driver’s knee panel. (Figure D)
6. Remove (1) Phillips screw from each side
console panel, and unclip to remove the
panels. (Figure E)
Continued on the next page
DASH DISASSEMBLY (CONT.)
3
(Figure E)
(Figure D)
(Figure C)
