Metra Electronics 95-7815B - Kit Preparation

1.800.221.0932
|
MetraOnline.com
KIT PREPARATION
6
(Figure A) (Figure B)
1. Remove the factory radio brackets to
release the factory climate controls/
screen for kit assembly. (Figure A)
2. Remove the (2) factory speed clips
from the bottom mounting tabs of the
radio, and slide them onto the bottom
mounting tabs of the 95-7815B radio
trim panel. (Figure B)
Continue to Kit Assembly
