Metra Electronics 95-8152 - Separating Radio from Climate Controls

95-8152 DASH DISASSEMBLY
LEXUS GS 300/400 1998-2005
2
Remove (2) screws from behind ash-
tray assembly. (
Figure D)
5
Unplug and remove radio/climate
controls assembly. ( Figure E)
6
Remove side brackets to separate the
radio from the climate controls.
(Retain the climate controls for reuse
during kit assembly.) ( Figure F)
7
Continue to kit assembly.
D
E
F
