G
H
2
Remove (1) 10 mm bolt beneath cli-
mate control behind pocket door.
(Figure E)
Unsnap climate control,
unplug and remove climate control.
(Figure F)
7
Remove (2) 10 mm bolts beneath
radio behind climate controls.
(Figure G)
8
Unsnap and remove entire center
panel around radio.
9
Remove (2) 10 mm bolts securing
radio. Unplug and remove radio.
(Figure H)
10
Continue to final assembly.
