95-9310B
6
1. Secure the climate bracket onto
the top of the climate and switch
panel housing. (Figure A)
2. Snap the climate control panel and
all switches into the climate and
switch panel housing. Connect all
electrical connectors, and then
secure the assembly into the lower
dash opening with the (4) factory
screws removed in step 9 of dash
disassembly. (Figure B)
3. Reassemble the dash in reverse
order of disassembly.
Climate and switch panel assembly
(Figure A)
(Figure B)
