Metra Electronics 99-1008 - Dash Disassembly; 2003-2006 Kia Sorento LX

99-1008
1
DASH DISASSEMBLY
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
Open ash tray and unsnap and
remove outside trim panels.
(Figure A)
T
ip: Start at the bottom of the trim
panels.
1
2
Remove (8) Phillips screw from the
radio trim panel. Disconnect any
plugs from the trim panel and then
remove panel.
(Figure B)
3
Remove (4) Phillips screw from radio
to remove radio.
(Figure C)
4
A
2003-2006 KIA SORENTO LX
B
C
D
Cut along the scored lines of the
radio housing’s mounting tabs.
(Figure D)
5
