2
99-1008
DASH DISASSEMBLY
2004.5- 2006 KIA SPECTRA
Using a flat blade screwdriver as a
pry tool, unsnap and remove the
center dash panel including the cli-
mate controls and vents from around
the radio.
(Figure A)
2
A
Remove (4) phillips screws to
remove radio.
(Figure B)
3
B
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
To Next Page
