Metra Electronics 99-2006 - Kit Assembly; DIN Radio Provision with Pocket; ISO Mount Radio Provision with Pocket

99-2006
KIT ASSEMBLY
2
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs down.
(Figure A)
1
Mount the ISO Brackets to the head
unit with the screws supplied with
the unit.
(Figure A)
1
A
A
B
Slide the aftermarket head unit into
the cage and secure. (
Figure B)
2
Slide the supplied pocket into the
unused opening.
3
Slide the supplied pocket into the
unused opening.
4
Slide the head unit into the radio
opening until the side clips engage.
(Figure B)
2
Snap the Trim plate into the Radio
Housing. (Figure B)
3
ISO MOUNT RADIO PROVISION WITH POCKET
B
DIN RADIO PROVISION WITH POCKET
