Kit Assembly 99-5600
2-Shaft head unit provision
1. Slide the aftermarket head unit into the
kit and secure with shaft nuts.
(Figure A)
2. Locate the factory wiring harness in the
dash. Metra recommends using the
proper mating adapter from Metra or
AXXESS. Re-connect the negative
battery terminal and test the unit for
proper operation.
3. Mount the rear support bracket to the
back of the unit. Snap the head unit/
kit assembly into the sub-dash (be sure
the rear support bracket engages the
support shelf in the dash). (Figure B)
4. Reassemble dash in reverse order
of disassembly.
(Figure A)
(Figure B)
