99-7316
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unclip and remove entire panel sur-
rounding radio and climate controls
including pocket assembly at bottom
of panel.
(Figure A)
2
2000-2005 HYUNDAI XG300/XG350
Remove (4) Phillips screws per side
to remove radio and climate control.
Note: It is not necessary to discon-
nect climate control.
(Figure B)
3
DASH DISASSEMBLY
A
B
To Next Page
