Metra Electronics 99-7316 - Kit Assembly - ISO DIN Head Unit Provision; Mount ISO Brackets; Install Head Unit and Trim

3
Mount the ISO Brackets to the head
unit with the screws supplied with
the unit. (Figure A)
1
Slide the head unit into the radio
opening until the side clips engage.
(
Figure B)
2
Snap the Trim plate into the Radio
Housing. (Figure B)
3
ISO DIN HEAD UNIT PROVISION
A
B
99-7316
KIT ASSEMBLY
