99-7320
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Open glove box and remove (2)
Phillips screws from top edge of
glove box opening and bottom edge
of wood trim below radio.
(Figure A)
2
HYUNDAI SONATA 2006-2008
Unclip and remove wood trim from
below radio and above glove box.
(Figure B)
3
Remove (1) Phillips screw per side
panel next to radio then unclip and
remove panels.
(Figure C)
4
Remove (6) Phillips screws from
radio to extract from sub dash.
(Figure D)
5
DASH DISASSEMBLY
A
B
D
C
To Next Page
