Metra Electronics 99-7334 - Kit Assembly; DIN Radio Provision

99-7334 KIT ASSEMBLY
DIN RADIO PROVISION
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs outward. (Figure A)
1
Slide the aftermarket radio into the
cage until it snaps into place. (Figure B)
2
Snap the pocket into the bottom
opening of the radio housing.
(Figure C)
3
2
A
B
C
*Note: Refer also to the instructions included with the aftermarket radio.
Continue to final assembly.
