Metra Electronics 99-7334 - ISO Mount Radio Provision

99-7334 KIT ASSEMBLY
3
A
B
C
D
ISO MOUNT RADIO PROVISION
Mount the ISO Brackets to the radio
using the screws supplied with the
radio. (Figure A)
1
Slide the radio/bracket assembly into
the radio housing until it snaps into
place. (Figure B)
2
Snap the ISO Trim plate onto the front
of the Radio Housing.
(Figure C)
3
Snap the pocket into the bottom
opening of the radio housing.
(Figure D)
4
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
