99-7337B DASH DISASSEMBLY
KIA SOUL 2010-11
1
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unclip and remove the radio/climate
control trim panel.
(Figure A)
2
Remove (4) Phillips screws securing
the climate control.
(Figure B)
3
Remove (4) Phillips screws securing
the radio.
(Figure C)
4
Continue to kit assembly.
A
B
C
To Next Page
