Metra Electronics 99-7337B - Kit Assembly and Head Unit Installation; Attach ISO Brackets to Housing; Install Head Unit into Assembly; Connect Wiring Harness and Adapter

2
99-7337B KIT ASSEMBLY
B
A
ISO HEAD UNIT PROVISION
Slide the head unit into the bracket /
radio housing assembly and secure
using the ISO screws supplied with
the radio.
(Figure B)
2
Locate the factory wiring harness in
the dash. Metra recommends using
the proper mating adapter from
Metra or AXXESS. Re-connect the
negative battery terminal and test
the unit for proper operation.
3
Reassemble dash in reverse order of
disassembly.
4
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
Attach the ISO brackets to the radio
housing. (Figure A)
1
