99-7402
DASH DISASSEMBLY
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
For vehicles with automatic trans-
mission, Unsnap and remove smaller
trim-ring from around shifter.
(Figure A)
For vehicles with manual transmis-
sion, Unscrew and remove shifter
knob.
(Figure A)
2
NISSAN 350Z 2003-2005
4
For vehicles with navigation, Unsnap
and remove navigation switch panel.
(Figure C)
B
A
C
D
1
For vehicles without navigation,
remove pocket mat, then remove
two screws that secure switch
mask.
(Figure D)
3
Unsnap and remove center console
trim panel including climate controls.
(Figure B)
5
To Next Page
