Metra Electronics 99-7402 - Kit Assembly Procedures; DIN Mount Radio Provision with Pocket

Attach the radio / housing assembly
to the radio trim panel using the
factory screws removed during
disassembly.
(Figure C)
1
Slide the radio into the DIN cage until
it snaps into place.
(Figure B)
4
99-7402
KIT ASSEMBLY
Secure DIN cage to radio housing by
bending the locking tabs outward.
(Figure A)
3
Continue to final assembly.
C
2
A
DIN MOUNT RADIO PROVISION WITH POCKET
B
3
Slide DIN cage (supplied with radio)
into the radio housing from the front.
(Figure A)
