Metra Electronics 99-7520B - Dash Disassembly

1. Unclip and remove the (2) trim panels
from the left and right side of the radio
trim panel. (Figure A)
2. Unclip and remove the trim panel
surrounding the radio and climate
controls. (Figure B)
3. Remove (4) Phillips screws securing the
radio. (Figure C)
Continued on next page
3
Dash Disassembly
99-7520B
2
3
4
2
3
4
2
3
4
A/C
(Figure A)
(Figure B)
(Figure C)
