99-7953
DASH DISASSEMBLY
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unclip and remove the (2) outside
trim panels.
(Figure A)
2
SUZUKI GRAND VITARA 2006-2008
Remove (6) Phillips screws securing
the radio and climate controls to the
sub dash.
(Figure B)
3
Remove the (2) Phillips screws
securing the factory radio bracket to
the radio/climate control assembly.
(Figure C)
4
Separate the bracket and factory
radio from the climate control.
(Figure D)
5
A
B
C
D
1
