99-8157B DASH DISASSEMBLY
LEXUS SC SERIES 1992-2000
A
B
1
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Push down on collar around base of
shift knob then remove (2) Phillips
screws then pull up on knob to
remove. (
Figure A)
2
Unclip and remove the shifter trim
panel. Tip: Start at the front with
ashtray open.
(Figure B)
3
Open cup holder lid then unclip and
remove the cup holder.
4
Continued on page 2.
