99-8157B DASH DISASSEMBLY
LEXUS SC SERIES 1992-2000
C
D
2
Remove (6) Phillips screws securing
the upper console trim panel then
unclip and remove the panel. (
Figure C)
5
Remove (8) screws securing the radio
and climate control assembly.
6
Remove (4) screws securing the
climate controls to the bracket
assembly and remove the climate
controls. (Retain the screws and cli-
mate controls for reuse during kit
assembly) (
Figure D)
7
Continue to kit assembly.
